xProduct Details
| Material | Cool Roll Steel Plate Q345B | Finish | Galvanised And Painted |
|---|---|---|---|
| Design | Modularized | Inverter Brand | Schneider |
| Reducer | KANGBO Make PIELI Helical Gearbox | Name | Building Site Hoist |
| Highlight | building hoist lift,building material hoist |
||
Product Description
Builders Hoist Lift SC200/200 VFC motor 2 tons payload KP-B05,B06
Advantage:
* Modular design for easy installation and maintenance.
* Standardized parts and components.
* Variable Frequency Control (VFC), with closed-loop.
* Composite Power & Control Cable, or Busbar.
* Smooth starting/stopping and running without jerk or vibration.
Production
All parts and components are processed by CNC machines and robots in tool fixtures.
Parts and components are universal and exchangeable.
| Technical Data | KP-B05, KP-B06 |
| Max. lifting height | 400 m |
| Payload capacity | 2,000 kg |
| Lifting speed | 0–36 m/min. |
| Cage size (internal) | 3.2(L)x1.5(W)*2.35(H) meter |
| Motor control | FC control |
| Engine power | 2x11 kw |
| Gearbox | Helical reducer |
| Safety device type | centrifugal brake |
| Type of mast | square column 650*650 mm with bolted rack |
| Length mast section | 1.508 m |
| Rack module | 8 |
