Rack Pinion Safe And Durable 2000Kg Payload Capacity Material Elevator Lifts
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200/200BZ KP-B09, KP-B10 |
| Minimum Order Quantity | 1 unit |
| Price | negotiate |
| Packaging Details | A 40'HQ container can load one unit 60 meter high single cage hoist |
| Delivery Time | 30 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 300 sets per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Material Elevator Lifts | Feature | Safety, Durable |
|---|---|---|---|
| Capacity | 2000Kg | Material | Q355B Cool Roll Steel Plate |
| Production | Processed By CNC Machines, Laser, Robots In Assembly Line. | Finishing | Sandblasting, Painted And Galvanised |
| Highlight | rack pinion lift,2000kg Elevator Lifts |
||
Product Description
Rack Pinion Safe and Durable Payload Capacity 2000Kg Material Elevator Lifts
About cage frame and surface: 1. The cage is boarded up by aluminum sheet, upper side is punched aluminum, lower side is solid aluminum. (It is anti-aging , anti-rust, light-weight and beautiful in its service life)
- 2. Sidewall of Wire Mesh or steel punched for cage is also available.
3. Main structure of cage is made of high-quality steel after bending.(The bent steel is firm, good vertically, stability. Moreover it ensure stable of the whole structure.) - 4. The frame surface color can be made by your requirement. (Red, yellow, blue, green, gray, orange etc)
Material Elevator Lifts Design
It is the truly modular rack and pinion hoist design, so the elevator drive devices and cars are generic and interchangeable.
The modular and standardizing system makes the Kangbo construction elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.
Material Elevator Lifts Standard Configuration
There is a electrical small crane available to facilitate the assembly of columns and doors on the floors.
Available in single or twin hoist cage configuration.
The construction rack and pinion elevators are Variable Frequency Drive (VFD), with low starting current and much less wear and tear, very smooth starting and stopping.
There is LED lighting inside construction elevator car.
Lighting inside construction elevator car is LED ceiling lamp
The construction material hoist cage roof doors are equipped with Interlock.
Material Elevator Lifts Parameters
| Technical Data | KP-B09, KP-B10 Material Elevator Lifts |
| Payload capacity | 2,000 kg |
| Lifting speed | 0–60 m/min. |
| Max. lifting height | 450 m |
| Cage width (internal) | 1.5 m |
| Cage length (internal) | 3.2 m |
| Cage height (internal) | 2.35 m |
| Motor control | FC control |
| Engine power | 2x23 kw/87Hz |
| Gearbox | Helical reducer |
| Safety device type | centrifugal brake |
| Power supply range | 380–500 V, 50 or 60 Hz, 3 phase |
| Mast section | Square column 650*650*1508 mm with bolted rack |
| Rack module | 8 |
