2 Ton Construction Material Hoist Rack Pinion With Variable Frequency Control
| Place of Origin | CHINA |
|---|---|
| Brand Name | KANGBO |
| Certification | TUV |
| Model Number | SC200, SC200/200 KP-B07, B08 |
| Minimum Order Quantity | 1 unit |
| Price | Negotiate |
| Packaging Details | one 40'HQ container for 1 set 60 meter high single cage hoist |
| Delivery Time | 30 days |
| Payment Terms | L/C, T/T |
| Supply Ability | 150 units per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Q355B Steel | Color | Yellow |
|---|---|---|---|
| Design | Modular | Control | Variable Frequency Control |
| Application | Construction | Purpose | Vertical Transportation |
| Finish | Sand Blasting And Paint, Galvanised | Work Mode | Mast Climbing |
| High Light | material hoist lift,material lift elevator |
||
Product Description
Construction Material Hoist Rack Pinion 2 ton Lifter SC200/200 KP-B07, B08
Features
Apply world famous inverter, and electrical appliances
Side open ground enclosure doors that are convenient for using and reliable.
FC control motors
Apply high efficiency and energy-saving helical gearbox
Multiple choice of cage doors.
Smooth running, no jerk, no vibration.
Production
Enlarged and thickened main steel channel of the cage frame, fully welded cage roof edges.
Made of Q345 cool roll steel plate, cut by Laser, processed by CNC machines and robots.
Technical data
| Item | KP-B07, B08 |
| Payload capacity | 2,000 kg |
| Lifting speed | 0–46 m/min. |
| Max. lifting height | 250/400 m* |
| Cage width (internal) | 1.5 m |
| Cage length (internal) | 3.2 m |
| Cage height (internal) | 2.35 m |
| Motor control | FC control |
| Engine power | 2x15 kw |
| Gearbox | Helical reducer |
| Safety device type | centrifugal brake |
| Power supply range | 380–500 V, 50 or 60 Hz, 3 phase |
| Type of mast | square column 650*650 mm with bolted rack |
| Length mast section | 1.508 m |
| Rack module | 8 |
| * Increased lifting height on request. 250 m with step-up transformer only. 400 m with step-up/step-down transformer. | |
